The Pylontech Force H1 is a high voltage battery storage system provided by Pylontech. The newly designed system provides easy connector to save valuable time for installers. The stacking system provides flexible configurations from 96V to 384V voltage and 7.1 kWh to 149.1 kWh capacity.

Features

• Flexibility Module Design
• Secured by self-developed cells, modules and BMS
• Reliable Performance
• 95% DOD
• 10+ years Technical Proven
• Be Expandable from 7.0-149.1kWh
• Be Suitable for Indoor/Outdoor installation
• Quick connector to save installation time

Why need Battery Storage System Pylontech Force H1?

High energy demand in the morning and evening But solar generation is most sufficient during the Mid-Day Battery storage system balance the feeding and demands.

High-efficiency for your power distribution Cut and save your electricity bills with this Pylontech Force H1.

Battery Storage System Pylontech Force H1 Specification

Battery Storage System: Force H1

• Battery System Capacity: 24.86 kWh
• Battery System Voltage: 336 Vdc
• Dimension (L*W*H): 600*380*1380mm
• Weight: 259 kg
• Depth of Discharge: 95%
• Charge/Discharge Current: 37A (Recommend) 40A (Max.)
• Multi-group: Max. 6 systems in parallel
• Communication Port: RS485, CAN
• Protection Class: IP 55
• Working Temperature: 0-50 °C
• Shelf Temperature:  -20~60°C
• Cycle Life: > 8000, 25°C
• Authentication Level: UL 1973/VDE2510-50 /IEC62619/IEC62477 /IEC62040/CE/UN38.3

Battery module: FH48074

• Nominal Voltage: 48Vdc
• Nominal Capacity: 74Ah
• Battery Capacity: 3552Wh
• Dimension (L*W*H): 600*380*170mm
• Weight: 37 kg

Main Controller: FC0500-40S

• Dimension (L*W*H): 600*380*150mm
• Weight: 11kgs
