120vac /240vac 6000W 48V off-grid solar inverter + mppt solar charger 80A, (PV input 145Vdc) + battery charger 60A

• LV6048 (split phase ready): 6000W/48V output, in 120v single phase / 208V, 240V split phase / 208V 3-phase
• 2X dual MPPT trackers up to 160A combined
• Parallel up to 3 units
• Pure sine wave output
• 50Hz & 60Hz support
• Programmable parameters
• Support either grid or generator input
• Genset starter dry contact
• FREE monitoring software.

36,000 BTU AC Running Off 1 x 6048!

Specifications

Standard Rating

• Continuous Output: 6000W
• System DC Volt: 48VDC
• AC Input Voltage: 110/120VAC (Phase-Neutral)
• Maximum Parallel: Up to 3 Units

PV INPUT / Solar Charging

• Max PV Input Power: 8000W (4000W each input)
• Max PV Input Volt: 145VDC (open circuit Voc)
• MPPT Range: 60 - 110VDC
• Number of PV Input: 2
• Max Charging Current: 160A (80A x 2)

Output Mode

• Output Waveform: Pure Sine Wave
• AC Output Mode: 120V L-N / 240V L1-L2 / 208V L1-L2 3 Phase
• Frequency: 50 / 60Hz, auto sensing
• Max Bypass Current: 40A
• Max Efficiency: >90%
• Max Utility Charging: 60A
• Max Utility + Solar Charging: 220A
• Max Bulk/Float Charge: 58.4V

Environmental / Mechanical Specifications

• Communication Port: USB/RS232/Dry Contact
• Operating Temp: 0-50C
• Operating Humidity: 0-90% RH (No Condensing)
• Dimension: 623 x 610 x 130mm
• Net Weight: 30Kg
