• LiFePO4 Chemistry - Deep Cycle Battery
• HEATED - Internal heating allows for charging in sub-zero conditions
• BLUETOOTH - iOS and Android Apps
• IP67 Rated, Dust and WATERPROOF
• Built-in Smart Battery Management System (BMS)
• Over charge and over discharge protection
• Over current and short circuit protection
• High & low temperature disconnects
• 3500+ Cycle life & Maintenance-free
• 11 Year Manufacturer Warranty

50Ah Specifications

• Weight: 34 (LBS)

DIMENSIONS

• Length: 13 (inches)
• Width: 10.25 (inches)
• Height: 11 (inches)

CONFIGURATION

• Cell Configuration: 8S
• Chemistry: LiFePO4

CURRENT

• Ah Capacity: 50Ah
• Max Continuous Discharge Amps: 100A
• Max Charge Current Amps: 150A (10 Seconds)
• Max Discharge Peak Current Amps: 150A (30 Seconds)
• Series | Parallel: Max (2) in Series | Max (4) in Parallel

VOLTAGE

• Voltage: 24V
• Max Charge Voltage: 29.2V
• Operating Voltage Range: 20 - 29.2V

TEMPERATURE

• Charge Temp Range: -20°C (-4°F) / 55°C (131°F) (with heating)
• Discharge Temp Range: -20°C (-4°F) / 60°C (140°F)
• Storage Temp: 0°C (32°F) / 35°C (95°F) (Max 12 Months)

100Ah Specifications

• Weight: 48.5 (LBS)

DIMENSIONS

• Length: 13 (inches)
• Width: 10.25 (inches)
• Height: 11 (inches)

CONFIGURATION

• Cell Configuration: 8S
• Chemistry: LiFePO4

CURRENT

• Ah Capacity: 100Ah
• Max Continuous Discharge Amps: 120A
• Max Charge Current Amps: 150A (10 Seconds)
• Max Discharge Peak Current Amps: 200A (60 Seconds)
• Series | Parallel: Max (2) in Series | Max (4) in Parallel

VOLTAGE

• Voltage: 24V
• Max Charge Voltage: 29.2V
• Operating Voltage Range: 20 - 29.2V

TEMPERATURE

• Charge Temp Range: -20°C (-4°F) / 55°C (131°F) (with heating)
• Discharge Temp Range: -20°C (-4°F) / 60°C (140°F)
• Storage Temp: 0°C (32°F) / 35°C (95°F) (Max 12 Months)
