• A Battery Charger with MPPT dual charging solution with 12V/24V boost and buck logic
• Compact & lightweight with IP67 waterproof rating
• Auto-switching charging mode while prioritizing green power
• CE, FCC, RoHS certified with comprehensive test reports
• Bluetooth Energy Monitoring with wired CAN communication

RENOGY 12V/24V IP67 50A DC-DC Battery Charger with MPPT

Introducing the RENOGY IP67 50A DC-DC Dual Input Battery Charger with MPPT, a slim, waterproof dual charging solution perfect for confined spaces. Equipped with intelligent boost and buck logic, it seamlessly accommodates 12V/24V-12V/24V voltage systems, elevating DIY possibilities to the uttermost. Renogy's exclusive intelligent charging logic prioritizes solar energy, efficiently charging your house battery while easing the load on generators.

This innovative product combines vehicle and solar power, automatically adjusting modes based on sunlight intensity. Maximizing energy utilization, it boasts a robust 50A current and an impressive 720W output power. Renogy IP67 Dual Input Battery Charger seamlessly switches to solar charging in ample sunlight and smoothly transitions to generator charging during low light, ensuring uninterrupted device power. Embrace an eco-conscious charging experience without compromising efficiency or space, redefining sustainable energy utilization.

Intelligent Dual Charging Mode

Intelligently combining vehicle and solar power, with automatic mode adjustments based on sunlight intensity.

Compatible with a Wider Range of Voltage

Expanding solar system DIY options for greater versatility.

Robust and Resilient Design

Drop-Resistant

Sheet metal casing gives the charger a robust shell that withstands drops and impacts.

Temperature-Resistant

Withstand extreme temperatures from -31℉ to 176℉ and maintain full-load operation even at 131°F.

Water-Resistant

The all-around glue filling design provides complete protection for the charger and ensures a high level of waterproofing.

Specifications

BASIC INFORMATION

• System Voltage: 12V/24V - 12V/24V
• Solar Input Voltage: 50 VDC
• Output Voltage: 9-32 VDC
• Alternator Input: 9-32 VDC
• Maximum Output Current Rating: 50A
• Output Power: 720W
• Battery Types: AGM/SLD , GEL ,FLD ,LI,USER
• Input Fuse Rating: 75A-100A
• Output Fuse Rating: 75A-100A
• Charging Efficiency: 94%
• Temperature Compensation: -3mV / ℃ / 2V (Non-Lithium) and 0mV / ℃ / 2V; no compensation (Lithium)
• Idle Power Consumption: 100mA

GENERAL DATA

• Model: RBC2125DS
• Terminal Range: 8AWG-4AWG
• Communication Protocol: Modbus ; RV-C
• Operating Temperature Range: -31℉ to 176℉/-35℃ to 80℃
• Storage Temperature Range: -40℉ to 176℉/-40℃ to 80℃
• Humidity: 0%-95%, No Condensation
• Maximum Operating Altitude: 3500m
• Enclosure Rating: IP67
• Dimensions: 7.01 x 4.78 x 1.47 in/178.2 x 121.5 x 37.5mm
• Weight: 4.10 lb / 1.86 kg
• Certification: CE;RoHS;FCC Part 15 class B
• Protection: Reverse Polarity Protection/Overvoltage Protection/Over Discharge Protection/Overcurrent Protection/Over Temperature Protection/Overcurrent Protection

WARRANTY INFORMATION

• Material and workmanship warranty: 3-year material warranty
• Charge Controllers: DCCS Dual Input
• Battery Chargers: DCCS Dual Input
